Description
Working cylinders convert compressed air into a straight push or pull. They are used on gearbox shift mechanisms, exhaust brakes, door gear and any auxiliary function that is operated from the vehicle’s air system rather than by hand.
Key data for this version: version Working Cylinder (with bellows), technical data Piston Ø25 mm · stroke 75 mm. The Buyukdemir reference is 1-1551.
It cross-refers to the original equipment numbers 81 11701 6028.
This is the Piston Ø25 mm · stroke 75 mm version; the nearest sizes in the same range are Piston Ø30 mm · stroke 48 mm (1-1550), Piston Ø40 mm · stroke 31 mm (1-1586), Piston Ø40 mm · stroke 50 mm (1-1561), Piston Ø40 mm · stroke 40 mm · Connection M12 X 1,5 (1-1560), Piston Ø50 mm · stroke 65 mm (1-1600).
Manufactured by Büyükdemir Otomotiv in Istanbul, Türkiye, a producer of compressed-air brake and pneumatic components for trucks and trailers since 1957.
