Description
Working cylinders convert compressed air into a straight push or pull. They are used on gearbox shift mechanisms, exhaust brakes, door gear and any auxiliary function that is operated from the vehicle’s air system rather than by hand.
Key data for this version: connection M12 X 1.5, piston / stroke Ø40 / 63 mm. The Buyukdemir reference is 1-1594.
It belongs to the Working Cylinder / Arbeitszylinder range in the Buyukdemir catalogue.
It cross-refers to the original equipment numbers 2998481, 2004719, 2244991, 2310764.
This is the Ø40 / 63 mm version; the nearest sizes in the same range are Ø40 / 58 mm (1-1592), Ø40 / 41 mm (1-1593), Ø35 / 61 mm (1-1591), Ø50 / 53 mm, Rod M10 (1-1590).
Manufactured by Büyükdemir Otomotiv in Istanbul, Türkiye, a producer of compressed-air brake and pneumatic components for trucks and trailers since 1957.
