Description
Test connections give a gauge a place to be fitted so that the pressure in a circuit can be read without breaking into a line. The valve inside closes as soon as the gauge is removed.
Key data for this version: thread M12 X 1,5 Spanner Size 17 mm, spanner size 17 mm. The Buyukdemir reference is 5-5305 A.
It belongs to the Test Connection range in the Buyukdemir catalogue.
It cross-refers to the original equipment numbers 463 703 995 0, 463 703 116 0, 463 703 105 0, 1506112, 1934927, 000 431 1431, 000 431 1531, 000 431 2031, 000 431 4831, 0 484 204 001, 81 98125 6039.
This is the M12 X 1,5 Spanner Size 17 mm version; the nearest sizes in the same range are M14 X 1,5, 17 mm (5-5305 D), M16 X 1,5, 17 mm (5-5305 B), M16 X 1,5, 22 mm (5-5305 C), M22 X 1,5, 28 mm (5-5305 E).
Manufactured by Büyükdemir Otomotiv in Istanbul, Türkiye, a producer of compressed-air brake and pneumatic components for trucks and trailers since 1957.
