Oil Pressure Valve 1-1074

Description

Pressure valves open at a set pressure and so hold the circuit behind them at a defined level. They are used where one part of a pneumatic system has to be kept clear of the pressure in another.

Key data for this version: thread / pressure 7,5 Bar. The Buyukdemir reference is 1-1074.

It cross-refers to the original equipment numbers 51 05400 6002, 51 05405 0007, 51 05405 0011, 51 05405 0012, 51 05405 5004.

This is the 7,5 Bar version; the nearest sizes in the same range are 6,5 Bar (1-1076), 5 Bar (1-1077), M12 X 1.75 (1-1047), M14 X 1.5 (1-1016), M27 X 1.5 (1-1075).

Manufactured by Büyükdemir Otomotiv in Istanbul, Türkiye, a producer of compressed-air brake and pneumatic components for trucks and trailers since 1957.
